Description of spot weld gun:
| SKU | 601015 | 601016 | 601017 | 601018 | 601019 |
| Power | 380V/50HZ(3PH) | 380V/50HZ(3PH) | 380V/50HZ(3PH) | 380V/50HZ(3PH) | 380V/50HZ(3PH) |
| Max Input Power | 350A | 190A | 230A | 250A | 220A |
| Output Current | 36VDC | 7.7A | 9.5A | 10.5A | 20A |
| Output Voltage | 41V | 34V | 36V | 36V | 42V |
| Duty Cycle | 35% 350A | 35% 190A | 35% 230A | 35% 250A | 35% 220A |
| Welding Wire Spec. | Dia 0.8-1.2 | Dia 0.8-1.0 | Dia 0.8-1.0 | Dia 0.8-1.2 | Dia 0.8-1.0 |
| Wire Feeding Speed | 2-25m/min | 2-25m/min | 2-25m/min | 2-25m/min | 2-25m/min |
| Welding Wire Reel Spec. | Dia 300mm/15kg | Dia 300mm/15kg | Dia 300mm/15kg | Dia 300mm/15kg | Dia 300mm/15kg |
| Size | 70*36*80cm | 68*36*68cm | 68*36*68cm | 68*36*68cm | 68*36*68cm |
| Weight | 95kg | 70kg | 80kg | 85kg | 60kg |
Features of spot weld gun:
1. Durable electric resistance self-induction type transformer for smooth and steady welding.
2. High quality cooling fan for long time use.
3. Combination rectifiers can make sure the machine could work in a high Temperature environment.
4. Automatic overheat protection.
5. Suitable for welding heavy duty vehicle and other heavy duty machines.
