Description
Details
-Fine welding,especiallu adapted to bicycle industry.
-Select functions of 2T/4T/repeating,making operation more handy.The product isdesigned with waterproof,dustproof and anti-erosionfunctions,increasing the reliability of the.
machine.Meanwhile,fan cooling efficiency reaches 100%,greatly increasing the duty cycle
-With both functions of TIG and MMA,can be adapted to long-time,high-quality welding of any metal materials.
Item# | 353167 | 353168 |
Input Power | 3phase AC380±15%V | 3phase AC380±15%V |
Rated input current | 9A | 02A |
No-load voltage | 60V | 60V |
Output current | 20-315A | 20-400A |
Rated output voltage | 22.6V | 26V |
Duty cycle | 60% | 60% |
Arc strike | HF | HF |
Efficiency | 85% | 85% |
Power factor | 0.93 | 0.93 |
Insulation class | F | F |
Pulse frequency(LF/MF) | 0.5-5/15-100Hz | 0.5-5/15-100Hz |
Pulse rate | 10-90% | 10-90% |
Arc strike/ending current | 20-315A | 20-400A |
Gas-in delay time | 1-10s | 1-10s |
Protection class | IP21S | IP21S |
Weight | 27.5kg | 28kg |
Size | 630x370x500mm | 630x370x500mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
