Description
Details
-Advanced inverter technology,high frequency,compact size and light weight,easy to carry.
-Stable and reliable welding current.
-Low No-load loss,low power consumption.
-Applicable for welding stainless steel and carbon steel.
Item# | 353152 | 353153 | 353154 |
Power voltage | 220-240V | 220-240V | 220-240V |
Rated input power | 3.2KVA | 3.9KVA | 4.5KVA |
Input voltage frequency | 50/60HZ | 50/60HZ | 50/60HZ |
No-load voltage | 56 | 56V | 56V |
Output current range | 10-160A | 10-180A | 10-200A |
Rated output voltage | 16.4V | 17.2V | 18V |
Duty cycle | 60% | 60% | 60% |
Efficiency | 85% | 85% | 85% |
Insulation class | F | F | F |
Protection class | IP21S | IP21S | IP21S |
Welding thickness | 0.3-5mm | 0.3-7mm | 0.3-9mm |
Usable electrode | 1.6-4.0mm | 1.6-4.0mm | 1.6-4.0mm |
Weight | 11/12kg | 11/12kg | 11/12kg |
Size | 460x270x345mm | 460x270x345mm | 460x270x345mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
