-Microprocessor control technology.
-Use IGBT technology,greatly improves the reliability of the machine.
-High duty cycle,greatly improves the efficiency of welder,energy saving.
-Small size,stable and durable quality.
| Item# | 353021 | 353022 | 353023 |
| Power voltage | 220-240V | 220-240V | 220-240V |
| Max input power | 3.5KVA | 4.5KVA | 5.5KVA |
| Efficiency | 85% | 85% | 85% |
| Power factor | 0.7 | 0.7 | 0.7 |
| Max No load voltage | 67V | 76V | 76V |
| Current range | 5-120A | 5-140A | 5-160A |
| Max current | 120@60% | 140@50% | 160@40% |
| Current at 100% | 120A | 120A | 130A |
| Usable electrode | 1.0-3.2MM | 1.0-4.0MM | 1.0-4.0MM |
| Insulation class | H | H | H |
| Protection class | IP21S | IP21S | IP21S |
| Weight | 6.7KG | 7.5KG | 7.7KG |
| Size | 425X270X335mm | 425X270X335mm | 425X270X335mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
