Description
Details
-Microprocessor control technology.
-Use IGBT technology,greatly improves the reliability of the machine.
-High duty cycle,greatly improves the efficiency of welder,energy saving.
-Small size,stable and durable quality.
| Item# | 353032 | 353033 | 353034 | 353035 |
| Power voltage | 220-240V | 220-240V | 220-240V | 220-240V |
| Rated input power | 2.4KVA | 2.8KVA | 3.5KVA | 4.5KVA |
| Fuse | 20A | 10A | 16A | 16A |
| Efficiency | 83% | 83% | 85% | 85% |
| Power factor | 0.7 | 0.7 | 0.7 | 0.7 |
| Max no-load voltage | 85V | 68V | 68V | 68V |
| Current range | 5-85A | 5-85A | 5-120A | 5-140A |
| Max current | 85@25% | 85@25% | 120@20% | 140@15% |
| Current at 60% | 60A | 70A | 80A | 80A |
| Usable electrode | 1.6-2.5mm | 1.0-2.5mm | 1.0-3.2mm | 1.0-4.0mm |
| Insulation class | H | H | H | H |
| Protection class | IP21S | IP21S | IP21S | IP21S |
| Weight | 7KG | 7KG | 7KG | 7KG |
| Size | 365X230X330mm | 365X230X330mm | 365X230X330mm | 365X230X330mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
