Details
-Main transformer uses super micri-crystal magnetic material.
-Using single tube IGBT,whose quality and price is better than mould IGBT.
-Air passage is of designed by protecting against water,dust and wind erosion,increases the stability of machine inner working.
| Item# | 353060 | 353061 |
| Power voltage | 380-400(3PH)V | 380-400(3PH)V |
| No-load voltage | 60V | 60V |
| Input voltage frequency | 50/60HZ | 50/60HZ |
| Output current range | 20-315A | 20-400V |
| Rated output voltage | 32.6V | 36V |
| Duty cycle | 60% | 60% |
| Efficiency | 85% | 85% |
| Insulation class | F | F |
| Protection class | IP21S | IP21S |
| Weight | 27KG | 27KG |
| Size | 630X370X500mm | 630X370X500mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
 Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
