Description
Details
-High welding quality,deep penetration
-Auto protection of over-voltage and over-current
-Be able to work continuously,it can balance automatically when voltage is fluctuation
-Suitable for welding all kinds of basic welding rod
| Item# | 353042 | 353043 | 353044 | 353045 |
| Power voltage | 220-240V | 220-240V | 220-240V | 120/230V |
| Rated input power | 5.3KVA | 7KVA | 5.3(MMA)/3.5(TIG)KVA | 3/7KVA |
| Input voltage frequency | 50/60HZ | 50/60HZ | 50/60HZ | 50/60HZ |
| No-load voltage | 76V | 76V | 76V | 76V |
| Output current range | 30-160A | 20-200A | 10-150A | 0-110/30-200A |
| Rated output voltage | 27V | 28V | 16.2-20.4(MMA)V/10.4-16.2(TIG)V | 24.4/28V |
| Duty cycle | 30% | 25% | 40%(MMA)/60%(TIG) | 80/25% |
| Efficiency | 85% | 85% | 85% | 85% |
| Insulation class | F | F | F | F |
| Protection class | IP21S | IP21S | IP21S | IP21S |
| Usable electrode | 1.6-4.0MM | 1.6-4.0MM |
1.6-4.0(MMA)MM/1.6-3.2(TIG)MM |
1.6-2.5/1.6-4.0MM |
| Weight | 11KG | 11KG | 11KG | 11KG |
| Size | 460X270X345mm | 460X270X345mm | 460X270X345mm | 460X270X345mmPacking&Shipping |
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
