Description
Details
-Good arc-starting and arc force,stable arc and little spatter
-High welding quality,deep penetration
-Auto protection of over-voltage and over-current
| Item# | 353053 | 353054 | 353055 | 353056 |
| Power voltage | 380-400V | 380-400V | 380-400V | 380-400V |
| Rated input power | 9KVA | 12.5KVA | 5.6KVA | 6.9KVA |
| Input voltage frequency | 50/60HZ | 50/60HZ | 50/60HZ | 50/60HZ |
| No-load voltage | 60V | 60V | 60V | 60V |
| Output current range | 20-240A | 20-280A | 20-200A | 20-250A |
| Rated output voltage | 30V | 31V | 28V | 30V |
| Duty cycle | 45% | 35% | 80% | 60% |
| Efficiency | 85% | 85% | 85% | 85% |
| Insulation class | F | F | F | F |
| Protection class | IP21S | IP21S | IP21S | IP21S |
| Weight | 15kg | 15kg | 17.5kg | 17.5kg |
| Size | 585x320x420mm | 585x320x420mm | 585x320x420mm | 585x320x420mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
