Description
Details
-Good arc-starting and arc force,stable arc and little spatter
-High welding quality,deep penetration
-Auto protection of over-voltage and over-current
| Item# | 353051 | 353052 |
| Power voltage | 220-240V | 220-240V |
| Rated input power | 5.3KVA | 7KVA |
| Input voltage frequency | 50/60HZ | 50/60HZ |
| No-load voltage | 76V | 76V |
| Output current range | 30-160A | 30-200A |
| Rated output voltage | 27V | 28V |
| Duty cycle | 30% | 25% |
| Efficiency | 85% | 85% |
| Insulation class | F | F |
| Protection class | IP21S | IP21S |
| Usable electrode | 1.6-4.0mm | 1.6-4.0mm |
| Weight | 11kg | 11kg |
| Size | 460X270X345mm | 460X270X345mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
