China manufacturing 1/2 ton electric chain i beam hoist 200079

1.This product has CE and GS certifications. Also it has ISO9001 authentication.
2.Safe thermal Protector provide you a reliable working space.
3.High lifting speed.
4.For energy saving and easy use.

Artikelposition: 200079

about Engdas Tools

engdas company

Beschreibung

Details

Description:

SKU 200079 080 081 082 083 084 085 086 087 088 089 090
Capacity(T) 0.5 1 1 1.5 2 2 2.5 3 3 3 5 10
Standard Lift 3m
Lifting Speed(m/min) 6.8 6.6 3.3 8.9 6.8 3.3 5.4 5.4 4.5 2.3 2.7 2.7
2.3 2.3 1.1 2.9 2.3 1.1 1.8 1.8 1.5 0.8 0.9 0.6
Motor Power 0.75/0.25 0.75/0.25 1.5/0.5 3/1 3/1 1.5/0.5 3/1 3/1 3/1 1.5/0.5 3/1 6/2
Rotation Speed(r/min) 2880/960
Voltage(V) 3 Phase/200-600V(Hz)
Trolley Power(kw) 0.4 0.75
Trolley Speed 11/21
I-beam 58-153 82-178 100-178 150-220
H(mm) 610 665 650 770 770 815 830 830 930 940 1015 1190
A(mm) 545 582 545 670 670 582 670 670 670 582 670 670
B(mm) 260 280 260 313 313 280 313 313 313 280 313 388
D(mm) 285 285 300 430 430 300 430 430 430 350 430 /
E(mm) 165 165 176 265 265 236 265 265 320 205 325 890
I(mm) 31 31 31 36 36 36 43 43 43 43 54 70
K(mm) 34 42 42 49 49 49 59 59 59 59 60 85
L(mm) 25 32 32 40 40 40 48 48 48 48 48 80
N(mm) 19 24 24 30 30 30 35 35 35 35 43 55
W(mm) 206 206 206 237 237 237 265 265 265 265 296 366
U(mm) 111 111 111 127 127 127 140 140 140 140 156 191
R(mm) 142 142 142 142 142 142 142 142 142 142 142 142
T(mm) 231 231 231 231 231 231 231 231 231 231 231 231
Chain(mm) 6.3 6.3 7.1 10 10 7.1 11.2 11.2 10 7.1 11.2 11.2

Advantages:

1.This product has CE and GS certifications. Also it has ISO9001 authentication.
2.Safe thermal Protector provide you a reliable working space.
3.High lifting speed.
4.For energy saving and easy use.
