Description
Details
F.R.L air filter combination air wick filter and fresh descriptions:
Name: F.R.L air filter combination air wick filter and fresh
SKU: 355257-355261
Operating Fluid: Air
Filtering elemet roughness: 40µm
Pressure Regulating Range: 0.05~0.85MPa
Max Adjustable Pressure: 0.95MPa
Ensured Pressure Resistance: 1.5MPa
Operating Temperature Range: 5~60℃
Suggested Lube: ISO VG32 or Same Grade Oil
Body material: Aluminum die casting forming
Body cup material: PE
Protective cup cover: Steel
| Specifications | ||||
| Model | Port Size(G) | Capacity of Filter Cup | Capacity of Oil Feed Cup | Weight(kg) |
| 355257 | 1/8'' | 15CC | 25CC | 0.42 |
| 355258 | 1/4'' | |||
| 355259 | 1/4" | 60CC | 90CC | 1.0 |
| 355260 | 3/8" | |||
| 355261 | 1/2" | |||
F.R.L air filter combination air wick filter and fresh features:
1. Check valve, gas will not return so it will not bring the magazine back to the regulator.
2. The interior is designed to make the product more durable and more comfortable.
3. Choosing aluminum alloy for body material, more durable.
4. The meter uses the standard module design, it can arbitrarily decompose the combination to meet the needs of different pneumatic system.
5. The oil mist filter in the compressed air can be filtered using an oil mist filter.
6. Polymer material and excellent sealing, high-strength heat so it is not easy to aging.
F.R.L air filter combination air wick filter and fresh advantages:
As we all know, the structure of the air source processor is simple, lightweight and easy to install. Its working medium is air mainly, Compared with the hydraulic medium, It is not easy to burn, so it is safer to use.Our filter combination are the perfect choice for the most demanding applications. By combining these three items, you will enjoy the excellent regulator flow characteristics with minimal pressure drop and high quality lubrication to your vital pneumatic components.And it has a check valve, so the gas will not return so it will not bring the magazine back to the regulator. Besides, The interior is designed to make the product more durable and more comfortable.
