Description:
| SKU | 200055 | 056 | 057 | 058 | 059 | 060 | 061 | 062 | 063 | 064 | 065 | 066 |
| Capacity(T) | 0.5 | 1 | 1 | 1.5 | 2 | 2 | 2.5 | 3 | 3 | 3 | 5 | 10 |
| Standard Lift | 3m | |||||||||||
| Lifting Speed(m/min) | 6.8 | 6.6 | 3.3 | 8.9 | 6.8 | 3.3 | 5.4 | 5.4 | 4.5 | 2.3 | 2.7 | 2.7 |
| 2.3 | 2.3 | 1.1 | 2.9 | 2.3 | 1.1 | 1.8 | 1.8 | 1.5 | 0.8 | 0.9 | 0.6 | |
| Motor Power | 0.75/0.25 | 0.75/0.25 | 1.5/0.5 | 3/1 | 3/1 | 1.5/0.5 | 3/1 | 3/1 | 3/1 | 1.5/0.5 | 3/1 | 6/2 |
| Rotation Speed(r/min) | 2880/960 | |||||||||||
| Voltage(V) | 3 Phase/200-600V(Hz) | |||||||||||
| H(mm) | 540 | 650 | 575 | 800 | 800 | 835 | 845 | 845 | 950 | 950 | 1030 | 1400 |
| A(mm) | 545 | 582 | 545 | 670 | 670 | 582 | 670 | 670 | 670 | 582 | 670 | 670 |
| B(mm) | 260 | 280 | 260 | 313 | 313 | 280 | 313 | 313 | 313 | 280 | 313 | 388 |
| D(mm) | 285 | 300 | 285 | 430 | 430 | 300 | 430 | 430 | 430 | 350 | 430 | / |
| E(mm) | 165 | 176 | 165 | 265 | 265 | 236 | 265 | 265 | 320 | 205 | 325 | 890 |
| I(mm) | 34 | 42 | 34 | 49 | 49 | 49 | 59 | 59 | 59 | 59 | 60 | 85 |
| J(mm) | 28 | 32 | 28 | 40 | 40 | 40 | 48 | 48 | 48 | 48 | 48 | 80 |
| K(mm) | 34 | 42 | 34 | 49 | 49 | 49 | 59 | 59 | 59 | 59 | 60 | 85 |
| L(mm) | 25 | 32 | 25 | 40 | 40 | 40 | 48 | 48 | 48 | 48 | 48 | 80 |
| M(mm) | 19 | 24 | 19 | 30 | 30 | 30 | 35 | 35 | 35 | 35 | 43 | 104 |
| N(mm) | 19 | 24 | 19 | 30 | 30 | 30 | 35 | 35 | 35 | 35 | 43 | 55 |
| Chain(mm) | 6.3 | 7.1 | 6.3 | 10 | 10 | 7.1 | 11.2 | 11.2 | 10 | 7.1 | 11.2 | 11.2 |
Advantages:
1.The controller is optional. Wireless controller also can be chosen.
2.With the Overload protection device and thermal Protector, the hoist have higher safety and reliability.
3.High lifting speed.
4.For energy saving and easy use.
