Description
Details
-Microprocessor control technology.
-Use IGBT technology,greatly improves the reliability of the machine.
-High duty cycle,greatly improves the efficiency of welder,energy saving.
-Small size,stable and durable quality.
Item# | 353036 | 353037 |
Power voltage | 220-240V | 220-240V |
Rated input power | 5.3KVA | 7KVA |
Input voltage frequency | 50/60HZ | 50/60HZ |
No-load voltage | 76V | 76V |
Output current range | 30-160A | 30-200A |
Rated output voltage | 27V | 28V |
Duty cycle | 30% | 25% |
Efficiency | 85% | 85% |
Current at 60% | 60A | 70A |
Insulation class | F | F |
Protection class | IP21S | IP21S |
Usable electrode | 1.6-4.0mm | 1.6-4.0mm |
Weight | 11kg | 11kg |
Size | 490x280x355mm | 490x280x355mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
