Description
Details
-Stepless adjustable current by roating the handle
-Suitable for the welding of small work pieces
-Portable and air-cooling structure
| Item# | 353104 | 353105 | 353106 | 353107 |
| Power voltage(3PH) | 230/400V | 230/400V | 230/400V | 230/400V |
| Rated output current | 60-160A | 70-200A | 80-250A | 80-300A |
| Rated duty cycle | 20% | 20% | 20% | 20% |
| Input power | 8.5KVA | 13.5KVA | 16.5KVA | 22KVA |
| Insulation class | F | F | F | F |
| Usable electrode | 1.6-3.2MM | 1.6-3.2MM | 2.5-4MM | 2.5-5.0MM |
| Weight | 30kg | 31kg | 35kg | 36kg |
| Size | 490X310X410mm | 490X310X410mm | 490X310X520mm | 490X310X520mm |
Packing&Shipping
According to the customer's need,we ship goods by air,sea and express.
Packiing:Standard Carton.
Delivery Detail:30-35 days after received the 30 percent deposit.
