Namur valve no lubricate two-position five-way description:
Name: Namur Valve
SKU: 356022-356025
Working Medium: Air(40 Micron Filtered)
Acting Type: Inner Guide Type
Lubricate: Not Necessary
Working Pressure Range: 0.15~0.9MPa
Max Pressure Resistance: 1.2MPa
Working Temperature: -5~60℃
Voltage Range: -15%~+10%
Power Consumption: AC380:2.5VA,AV220:2.0VA,AC110V:2.5VA,AC24V:3.5VA,DC24V:3.0W,DC12V:2.5W
Insulation&Protection Class: F Class.IP65
Max.Frequency: 5 Times/Sec
Shortest Activate Time: 0.05 Second
Namur valve no lubricate two-position five-way features:
1. Switch signal control, so it is very convenient to connect with the industrial computer.
2. The composition of the automatic control system is much simpler, so the price is much lower.
3. The use of flat diaphragm structure, enhancing the service life of the product.
4. Supporting the ring, so that the product more tightly sealed.
Namur valve no lubricate two-position five-way advantages:
Adopting the gas as the power source, so the pneumatic control valve is relatively safe. And if it were leaking, the gas can be discharged directly. Compared with the hydraulic and electric medium, It do not have any pollution to the environment, It has a high security at the same time. As an actuator of automated instrument, solenoid valves have seen sharp increase in use in recent years. It is an energy-saving product. As the solenoid valve is controlled by switch signal, it’s very convenient to connect it to computers. In today’s world where computer use is widespread and its price drops significantly, the advantages of the solenoid valve is even more obvious. And it has switch signal control, so it is very convenient to connect with the industrial computer. Besides, The composition of the automatic control system is much simpler, so the price is much lower.
