Description:
| Model | 200001 | 200002 | 200003 | 200004 | 200005 | |
| Capacity(T) | 0.5 | 1 | 2 | 3 | 5 | |
| Standard Lift(m) | 3 | 3 | 3 | 3 | 3 | |
| Lifting Speed(m/min) | 4.5 | 4.5 | 2.25 | 1.5 | 0.75 | |
| Motor Power | 0.8 | 1.1 | 1.1 | 1.1 | 1.1 | |
| Power Supply(V) | 3 Phase/ 380V(50Hz) | |||||
| Control Voltage(V) | 24V | |||||
| Insulation Grade | F(155°) | |||||
| Rating | 40% | |||||
| Spec. of Chain | Φ7.1×21 | |||||
| No. of Chain | 1 | 1 | 2 | 3 | 5 | |
| Working Level | M4 | M4 | M4 | M4 | M3 | |
| Running Test Load(T) | 0.625 | 1.25 | 2.5 | 3.75 | 6.25 | |
| Length of Cable(m) | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | |
| Net Weight(Kg) | 44 | 45 | 50 | 60 | 80 | |
| Extra weight per meter of extra lift(Kg) | 1.1 | 1.1 | 2.2 | 3.3 | 5.5 | |
| Hmin(mm) | 550 | 550 | 600 | 700 | 1000 | |
| Dimension(mm) | A | 250 | 250 | 250 | 250 | 250 |
| B | 250 | 250 | 250 | 250 | 250 | |
| C | 106 | 160 | 72 | 72 | 72 | |
| D | 126 | 126 | 160 | 160 | 160 | |
| E | 32 | 32 | 35 | 40 | 50 | |
| F | 185 | 185 | 218 | 218 | 218 | |
Advantages:
1.The power supply could be customized.Triphase single speed engine car hoist lift for sale
2.This product has CE and GS certifications. Also it has ISO9001 authentication.
3.This product is combining and applying technology from Japan and Germany.
4.The small size and light weight makes the product easy to take.
5.Easier operation and smart appearance.
6.Safe thermal Protector provide you a reliable working space.
7.Suitable to use in factories, mines, docks, shops and warehouses.
8.Suitable to working in low space.
