High quality portable 2 ton electric chain hoist

Description

Details

Description:

SKU	200067	068	069	070	071	072	073	074	075	076	077	078
Capacity(T)	0.5	1	1	1.5	2	2	2.5	3	3	3	5	10
Standard Lift(m)	3
Lifting Speed(m/min)	6.8	6.6	3.4	8.8	6.6	3.3	5.4	5.4	4.4	2.2	2.7	2.7
Motor Power	0.75	1.5	0.75	3	3	1.5	3	3	3	1.5	3	3*2
Rotation Speed(r/min)	1440
Voltage(V)	3 Phase/200-600V(Hz)
Trolley Power(kw)	0.4						0.75
Trolley Speed(r/min)	11/21
I-beam	58-153			82-178			100-178					150-220
H(mm)	610	665	650	770	770	815	830	830	930	940	1015	1190
A(mm)	455	455	520	615	615	520	615	615	615	520	615	630
B(mm)	240	240	260	295	295	260	295	295	295	260	295	315
D(mm)	285	385	300	430	430	300	430	430	430	350	430	/
E(mm)	165	165	176	265	265	236	265	265	320	205	325	890
I(mm)	31	31	31	36	36	36	43	43	43	43	54	70
K(mm)	34	42	34	49	49	49	59	59	59	59	60	85
L(mm)	25	32	25	40	40	40	48	48	48	48	48	80
N(mm)	19	24	19	30	30	30	35	35	35	35	43	55
W(mm)	206	206	206	237	237	237	265	265	265	265	296	296
U(mm)	111	111	111	127	127	127	140	140	140	140	156	191
R(mm)	142	142	142	142	142	142	142	142	142	142	142	142
T(mm)	231	231	231	231	231	231	231	231	231	231	231	142
Chain(mm)	6.3	7.1	6.3	10	10	7.1	11.2	11.2	10	7.1	11.2	11.2

Advantages:

1.Easier operation and smart appearance.
2.Suitable to use in factories, mines, docks, shops and warehouses.
3.The controller is optional. Wireless controller also can be chosen.
4.With the Overload protection device and thermal Protector, the hoist have higher safety and reliability.
